Description
These compressors are available in diesel/electric powered version. These compressors are designed & manufactured for various applications lihe DTH Drilling, Coal Drilling with Excavator Attachments, Oil & Gas Explorations, Pigging, Sand Blasting, Tunnelling, Quarrying, Piling & Road Construction.
Technical Specification:
MODEL | DS575 |
Free Air Delivery | 575CFM |
Normal Working Pressure | 225PSIG |
Ambient Temperature Range | 5 - 52 ˚C |
Fuel Tank | 250 (Liter) |
Air outlet valve with trolley (Wheeled) | - |
Air outley valve without trolley (Skid/ Rig) | 1 no of 2" |
Engine make | Ashok leyland |
Rated engine power | 220(162)HP(kW) |
Overall dimention with trolley (Wheeled) | - |
Overall dimension without trolley (Skid/ Rig) | 2850 X 1420 X 1650 L X B X H, MM |
Dry weight of the Package with trolley (Wheeled) | - |
Dry weight of the Package without trolley (Skid/ Rig) | 2700Kg |
Mounting type | Trolley/Skid |
