Description
The TrueComp DS550 Diesel Portable Air Compressor is a truly next-generation, high pressure and high-airflow compressor delivering 550 CFM Free Air Delivery at 220 PSI. Designed for the toughest field conditions, DS550 is engineered to serve construction, water well drilling, and mining applications with maximum reliability, fuel efficiency, and operator safety.
Technical Specifications – DS550
Description | Unit of Measure | DS550 |
General | ||
Free Air Delivery | CFM | 550 |
Normal Working Pressure | PSI | 220 |
Maximum Ambient Temperature | °C | 52 |
Compressor Oil Fill Capacity (Refill) | Litres | 50 |
Fuel Tank Capacity | Litres | 210 |
Engine | ||
Engine Make | - | Ashok Leyland |
Engine Model | - | H6 |
Rated Engine Power | HP | 220 |
Hot Surface Protection | - | - |
Size Weight & Dimenssion | ||
Overall Dimension with Trolley (Wheeled) | L × B × H (mm) | 4050 × 1800 × 2100 |
Overall Dimension without Trolley (Skid/Rig | L × B × H (mm) | 2857 × 1420 × 1600 |
Working Weight with Trolley | Kg | 2671 |
Working Weight (Skid/Rig) | Kg | 2115 |
Mounting Type | - | Trolley/Skid |
